E 7
ANTRIEBSTECHNIK
3. Control Cabinet Installation
3.1 Ambient Conditions
Altitude of site max. 3000 m ––
A power reduction of 1 % per
100 m must be taken into account for site altitudes of 1000
m and more above sea level, i.e. 1500mNN = 95% P
Nominal
Max. permissible Servon Controller Servo Motor
limit values: KEB COMBIVERT S4 KEB COMBIVERT SM
Coolant inlet temper.- /
Ambient temperature -10 °C…+45 °C -5 °C…+40 °C
during operation
Storage temperature -25 °C…+70°C -25 °C…+70°C
Transport temperature -25 °C…+70°C -25 °C…+70°C
Relative humidity max. 95 %
no condensation
(identification "F" DIN 40040)
3.2 Type of Protection
Servo controller KEB COMBIVERT S4: IP 20
Servo motor KEB COMBIVERT SM: IP 65
Shaft gland of servo motor: IP 64
The type of protections are warranted only with correct
installation and connection of the components.
– Stationary installation and earthing of the servo controller KEB COMBIVERT
S4.
– At the installation of the servo controller observe minimum distance to adjacing
elements (see Installation Instructions).
– No moisture or water shall penetrate into the servo controller.
– Avoid penetration of dust into the servo controller. For installation in a dust-
proof housing sufficient heat dissipation must be provided.
– Do
not
operate the servo system KEB COMBIVERT S4 in explosion-protected
rooms.
– Ensure sufficient heat emmission of the servo motor.
– Protect servo controller and servo motor against aggressive gases and liquids.
– Avoid any impacts or shocks on the servo motor.
– Use suitable devices for fitting or taking off drive elements on the motor shaft
(toothed wheels, belt-pulleys, clutches etc.)
If other consumers which produce electric or magnetic fields or which effect the
power supply are located in the vicinity of the servo controller, they must be
positioned as far away as possible from the servo controller and steps must be
taken to suppress interferences.
3.3 Installation Instructions
