100
8. Rear Wheel/Rear Suspension
Preparing documents -----------------8.1
Failure diagnosis ----------------------8.2
Rear wheel -----------------------------8.3
Rear absorber --------------------------8.4
8.1 Preparing documents
Work Instructions
The surface of the brake drum and brake shoes shall not be stained with oil spots.
Preparing Principles
Item Standard (mm) Limit for use (mm)
Vertically 2.0
Rear wheel
shimmy
Horizontally 2.0
Locking torque force
Fixing nuts for the rear wheel 100-113 N·m
Fixing bolts of rear absorber (top) 37 - 44 N·m
Fixing bolts of rear absorber (bottom) 22 - 29 N·m
8.2 Failure diagnosis
8.2.1ear wheel shimmy
Deformed rim.
Tire failure.
Rear wheel not fixed.
Low tire pressure.
8.2.2 Too soft absorber
Elastic fatigue of spring
