118
Measure the outer diameter of the plunder.
Limit for use: 2.61mm。
Carburetor
1. screw 2. float chamber 3. needle valve assembly 4. float 5. float pin 6. main metering jet 7. idling jet 8.
main foam pipe 9. idle adjusting screw
Note: Gasoline is very
dangerous. Fire is strictly
forbidden in workplace.
After the carburetor is
disassembled, block the intake
manifold with cloth in case
that any foreign matter enters.
