115
10.3 Fuel pump
10.3.1 Disassembly
Loosen the bolt and remove the fan cowl assembly.
Loosen fan screws and remove the fan.
Remove the right cover.
Remove the worm wheel from the crank and
also the fuel pump assembly.
导风罩
Fan
Screw
磁电机定、转
子、支架
Right cover
Fuel pump
