KEEWAY FACT 50 4T User Manual

99
Rear wheel
1 outer tire 130/70-12 2 rim 3.50×12 3 valve cap 4 valve 5 nut M16Χ1.5 6 brake shoe assembly 7 brake
shoe spring 8 rear indicator 9 rear brake camshaft 10 rear brake return spring 11 rear brake swing arm
assembly 12 rear swing arm mounting bolt 13 O-ring
A Tire size: 130/70-12
B Rim size: 3.50×12
Rim run-out limit:
Vertically: 2.0mm
C
Horizontally: 2.0m
m
D
Torque of fixing nut 5 of the
rear wheel: 100-113N·m
E
Auth. No. of rear tire: E11
75R 000216
