47
quick: 30 minutes
Charging completed: open circuit voltage: above 12.8V
Carburetor
Idle speed adjustment
* Note
Idle speed adjustment is carried out when the engines warms up.
It is carried out when the engines warms up.
Operate the engine and connect the engine rotary meter.
Adjust the adjusting screws of the throttle cable.
Idle speed: 1800±100rpm/min
When it rotates unstably at idle speed or it is unsmooth during
oil filling slightly, adjust the idle speed adjusting screw.
Ignition timing
* Note
Check the ignition system when the ignition timing is
incorrect.
Remove the fixing bolt.
Remove the guard.
Use an ignition timing lamp to check ignition timing.
Cylinder pressure
Operate it when the engine warms up.
Remove the seat the body guard.
