KEEWAY FACT 50 4T - Failure diagnosis; Startup motor; Starter relay

70
3. Startup System
Preparing documents---------------3.1
Failure diagnosis -------------------3.2
Startup motor------------------------3.3
Starter relay--------------------------3.4
3.1 Preparing documents
Work Instructions
Disassemble the startup motor on the engine.
For the disassembly of the startup clutch, please comply with related regulations
Preparing principles
Item Standard Limit for use
Length of the brush of the startup
motor
6.2mm 3mm
Bushing of the startup idler shaft 8.3mm
Outer diameter of the startup idler
shaft
7.94mm
Tightening torque force
Bolts for the clutch cover of the startup motor 12 N·m
Retaining nut for the clutch of the startup motor 95 N·m
Tools
Spanner for retaining nuts
Universal fixing spanner
