KEEWAY FACT 50 4T - Preparing Documents; Failure Diagnosis; Fuel Tank;Seat

106
9.Fuel Tank/Seat
Preparing documents -----------9.1
Failure diagnosis ---------------9.2
Fuel tank/seat -------------------9.3
9.1 Preparing documents
Work Instructions
It shall be dismantled far from fire sources.
Turn the fuel switch to “OFF” when the fuel tank is dismantled.
Tighten all the bolts and screws to the required torque value for assembly.
After assembly, check whether all the parts are correctly installed and operated.
Preparing Principles
Item Standard Limit for use
Gasoline tank capacity 6.0±0.2L /
Tightening torque force
Fixing screws for the rear rack 22-29 N·m
Fixing bolts for the fuel tank 5 - 9 N·m
Fixing bolts for the helmet box 5 - 9 N·m
9.2 Failure diagnosis
Decreasing gasoline
Natural consumption of gasoline
Leakage of gasoline
