112
Inspection and Maintenance of Engine
Table of Torque Force of Engine Fasteners
Name of fastening parts and fasteners
Tightening torque（N·m）
Fan cowl locking bolt
Cylinder cover locking nut
Spark plug
Air intake pipe locking bolt
Cooling fan blade locking screw
Flywheel locking bolt
Locking screw for the magnetor stator coil
Right crankcase locking bolt
Bearing plate locking bolt
Double-end stud for cylinder double-head
Motor fixing bolt
Locking screw for the crankcase left cover shade
Locking bolt for the crankcase left cover
Locking nut for the drive wheel
Locking nut for the driven wheel
Locking nut for the driven wheel clutch
Locking screw for the overrunning clutch outer ring
Locking screw for the electric starter idler plate
Locking bolt for the gearbox cover
Locking bolt for the oil drain hole of the left crankcase
Locking nut for the locating pin shaft of left crankcase
10-12
15-18
22-25
10-12
10-12
45-50
10-12
10-12
10-12
15-18
10-12
10-12
10-12
40-45
40-45
55-60
10-12
10-12
10-12
18-22
18-22
