13
Fig.1-15 Fig.1-16
2．Tools for repairing the chassis
Table and drawing (1-17, 1-18) of ordinary tools and special tools for disassembling/assembling chassis parts are
as follows:
Table 1-17
Name Remark
Torque spanner
Inner hexagon spanner
Socket spanner
Micrometer
Magnetic rack, V-block
Dial indicator
Vernier calipers
Circlip pliers
Screwdriver with striking cap
Tool for assembling oil seal of front fork
Tool for hammering seal of front fork
Steering nut spanner
Fig. 1-19
Fig. 1-20
Fig. 1-21
Fig. 1-22
Fig. 1-23
Fig. 1-24
Fig. 1-25
Fig. 1-26
Fig. 1-27
Fig. 1-28
Fig. 1-29
Fig. 1-30
(1) Ordinary tools for repairing the chassis
Table 1-18 (continued)
Fig. 1-19 Fig. 1-20
1. socket head 2. crank handle 3. ratchet spanner
4. connecting rod
