30
Y N
Y N
Diagnosis on insufficient battery charging
Insufficient battery charging
Check whether the brake lamp is always light.
Adjust or replace the
brake lamp switch.
Leakage current smaller than the required.
Leakage current larger than the
required (normally it shall be no
more than 1mA).
Check whether the charging coil of the magnetor is short-circuit.
Short circuit between the rectifier or
the rectifier regulator or the battery
and the ignition switch.
Replace the
charging coil
1. Check whether the battery electrolyte is enough.
2. Check whether the battery electrolyte is diluted.
3. Check whether the battery electrode plates are
vulcanized or short-circuit.
Set the ignition switch to “OFF”; remove the negative cable from the battery;
connect the negative electrode of the ammeter to the battery negative terminal and
the positive electrode to the positive terminal; check current leakage.
