15.2 Selecting Auxiliary Mode
• In the KEF Connect App, tap the Auxiliary Mode button (AUX) to switch to Auxiliary
mode.
• Alternatively, press the source button on the remote control.
• The LEDindicatorlightofthePrimarySpeakerilluminatesyellowbrieyandthen
fades out when AUX mode is selected.
You can assign Auxiliary mode as a second wake-up source to turn on
the speakers automatically when there is audio input through the auxiliary
connection. See chapter “Power Saver – Second Wake-Up Source”.
15.3 Playback Controls
All playback controls (except adjusting volume) must be done on the connected device.
The volume can also be adjusted on the remote control.

KEF LS60 Wireless Specifications

General

Power Input	100-240V, 50/60Hz
Frequency Response	31 Hz - 24 kHz (-6dB)
Connectivity	Wi-Fi, Bluetooth 4.2, Ethernet
Streaming Features	AirPlay 2 Google Chromecast UPnP Compatible
Streaming Services	Spotify Connect Tidal Amazon Music Qobuz Deezer
Input Resolution	Up to 24bit/192kHz
Supported Formats	FLAC, WAV, AIFF, ALAC, MP3, AAC, WMA
Inputs	HDMI eARC, Optical, Analog RCA, RJ45 Ethernet
Outputs	Subwoofer Out
Weight	31.2 kg per speaker
Finish Options	Mineral White, Titanium Grey, Royal Blue
Drivers	Uni-Q driver array with 19mm aluminium dome tweeter, 100mm aluminium cone midrange; 4 x 135mm aluminium cone woofers
