3. Unpacking
Follow the instructions below to unpack the speakers.
1. Detach all locking devices from the box.
2. Remove the top box cover and protective inlay.
3. Remove the corner reinforcers.
4. Open the outer box and remove it.
5. Open the bottom box cover and slide out the speaker with the protective inlays.
6. Slightly tilt the speaker to the left and remove the right protective inlay.
7. Slightly tilt the speaker to the right and remove the left protective inlay.
8. Remove the protective cover from the speaker.
Your pair of speakers are packed seaparately in two boxes with the same serial
number (see the examples below which are labels found on the packaging
boxes). The two speakers with the same serial number will be paired
automatically.
In case the serial numbers on the boxes are not the same, follow the
instructions here to pair them.

KEF LS60 Wireless Specifications

General

Power Input	100-240V, 50/60Hz
Frequency Response	31 Hz - 24 kHz (-6dB)
Connectivity	Wi-Fi, Bluetooth 4.2, Ethernet
Streaming Features	AirPlay 2 Google Chromecast UPnP Compatible
Streaming Services	Spotify Connect Tidal Amazon Music Qobuz Deezer
Input Resolution	Up to 24bit/192kHz
Supported Formats	FLAC, WAV, AIFF, ALAC, MP3, AAC, WMA
Inputs	HDMI eARC, Optical, Analog RCA, RJ45 Ethernet
Outputs	Subwoofer Out
Weight	31.2 kg per speaker
Finish Options	Mineral White, Titanium Grey, Royal Blue
Drivers	Uni-Q driver array with 19mm aluminium dome tweeter, 100mm aluminium cone midrange; 4 x 135mm aluminium cone woofers
