K-MIX EDITOR
108
• Aux 3 = Monitoring outputs 7 & 8
• Ch. 1–8 = Monitoring input channels 1–8
• Discrete Stereo Output = Act as its own output bus (outputs 9 & 10)
Click one of the buttons to change the headphones monitoring point.
5.2.1.4 – MAIN OUTPUT CHANNEL STRIP
The main output bus (outputs 1 & 2) has its own channel strip. The effects in this channel strip are
applied to the entire stereo mix going to the main outputs.
With a few exceptions, the main output bus channel strip is nearly identical to the channel strips of the 8
input channels.
As you may be able to see, there are a few differences from the input channel strips.
1. There is no Input Trim, Rumble Filter, or Stereo Pairs.
2. There is no Routing section.
3. There is an additional Reverb Level section.
Apart from those differences, the main output channel strip behaves the same as the input channel
strips.
Only one option may be selected at a time. It is not possible to select multiple
monitoring points simultaneously.
HI
Level
0.00 dB
0.00 dB
24.00 dB
-70.00 dB -24.00 dB
-4.51 dB
10 ms
10 ms
50 ms
50 ms
0.00 dB1.00
10.00
0.00 dB
3.24 kHz
346 Hz
276 Hz
Level
Level
Q
Freq
Thresh Ratio
Thresh Gain Reduc.
Attack Release
Return Level
ReleaseAttack
Freq
Freq
MID
LOW
EQUALIZER COMPRESSOR GATE REVERB
MAIN
Makeup Gain
