K-MIX HARDWARE
65
EXAMPLE USE
1. Press the [EQ] button to go into EQ Mode.
2. Select a channel by pressing its channel select button.
3. Press and hold the [SHIFT] button.
4. While [SHIFT] is still held down, adjust rotary 1, 3, or 4 to alter the Low Frequency, Mid Q, or
High Frequency parameters.
5. Release the [SHIFT] button to go back to normal rotary behavior.
4.2.16 – VERB
The [VERB] button is used to enter K-Mix’s “Reverb Mode” — here you can adjust the reverb
settings for K-Mix’s global reverb send.
4.2.16.1 – WHAT DO THE CONTROLS DO?
FADER BEHAVIOR
In Reverb Mode, faders 1–8 are used to control the reverb “send level”, the amount of signal being
passed into the global reverb effect for input channels 1–8. The master fader is used to control the
overall level of the reverb that is mixed in to the main output bus, outputs 1 & 2.
• Move a fader up to increase the reverb send level for that channel.
• Move a fader down to decrease the reverb send level for that channel.
ROTARY BEHAVIOR
The four rotaries are used to adjust the global reverb’s settings.
• Rotary 1 = PreDelay
• Rotary 2 = Damping
• Rotary 3 = Diffusion
• Rotary 4 = Decay
Rotaries act like traditional knobs; the minimum value is at 7 o’clock and the maximum value is at 5
o’clock.
• Move the rotary clockwise to increase the current parameter’s value.
• Move the rotary counterclockwise to decrease the current parameter’s value.
Since the faders function the same as they do in Mains Mode, [SHIFT] can also be
used to solo and mute channels via the faders.
