K-MIX HARDWARE
76
4.3.3.2 – INPUT CHANNEL PARAMETERS
All input channel parameters are controllable via MIDI, the exceptions being Stereo Pairs, Solo, and Aux
Pre/Post switches.
As stated in the previous section, 4.3.3.1 – MIDI Channel, each input channel’s MIDI controllable
parameters are separated by MIDI channel; sending messages on MIDI channel 1 will control input
channel 1, MIDI channel 2 will control input channel 2, and so on. This is nice because the CC number
for each parameter (such as EQ High Frequency) can remain the same, just change the MIDI channel.
The following list details the parameters that may be controlled, and the MIDI CCs that are used to
control them.
External MIDI messages for controlling Mains panning, Aux 1–3 panning, and
Aux 1–3 send levels will be ignored when surround panning is enabled; these
parameters are not accessible when using surround.
• Fader/Volume Level = CC 1
• Mute = CC 2
• EQ Bypass = CC 3
• EQ High Boost/Cut Level = CC 4
• EQ High Frequency = CC 5
• EQ Mid Boost/Cut Level = CC 6
• EQ Mid Frequency = CC 7
• EQ Mid Q = CC 8
• EQ Low Boost/Cut Level = CC 9
• EQ Low Frequency = CC 10
• Gate Bypass = CC 11
• Gate Threshold = CC 12
• Gate Attack Time = CC 13
• Gate Release Time = CC 14
• Gate Gain Reduction = CC 15
• Compressor Bypass = CC 16
• Compressor Threshold = CC 17
• Compressor Attack Time = CC 18
• Compressor Release Time = CC 19
• Compressor Ratio = CC 20
• Compressor Makeup Gain = CC 21
• Left/Right Panning (to Mains) = CC 22
• Aux 1 Send Level = CC 23
• Aux 1 Panning = CC 24
• Aux 2 Send Level = CC 25
• Aux 2 Panning = CC 26
• Aux 3 Send Level = CC 27
• Aux 3 Panning = CC 28
• Input Trim = CC 29
