K-MIX EDITOR
97
5.2 – TABS
The top of the K-Mix Editor window houses the tab switching buttons. There are ve available tabs: Channel
Strip, Reverb, Surround, MIDI, and USB. Clicking one of these will display related parameters in the main tab
area.
5.2.1 – CHANNEL STRIP TAB
The Channel Strip tab houses all of the trims, DSP, and routing options available
for each input and output channel, just like on a traditional mixing console.
There are four types of channel strips:
• Input channel strips
• Aux channel strips
• Phones channel strip
• Mains channel strip
Each type of channel strip contains different available options.
5.2.1.1 – INPUT CHANNEL STRIP (1–8)
Each of the 8 input channels have their own channel strip with identical options. Each input channel
strip has its own Input Trim, Rumble Filter, Stereo Pair switch, EQ, Gate, Compressor, and Routing
Sections.
To access one of the Input Channel Strips, simply click one of the channel select buttons above faders
1–8 (in the editor). The editor will automatically display the appropriate channel strip in the main tab
area.
Input Trim
MAIN
HI
Level
0.00 dB
0.00 dB
24.00 dB
-70.00 dB -24.00 dB
10 ms
10 ms
50 ms
50 ms
1.50 dB
0.00 dB1.00
10.00
0.00 dB
3.24 kHz
346 Hz
276 Hz
224 Hz
Level
Level
Q
Freq
Thresh Ratio
Thresh Gain Reduc.
Attack Release
Pan
Send
Level
Send
Level
Send
Level
Pan
Pan Pan
ReleaseAttack
Freq
Freq
MID
LOW
AUX 1
AUX 2 AUX 3
Rumble Filter
EQUALIZER COMPRESSOR GATE ROUTING
ONE
POST
POSTPOST
Makeup Gain
Stereo Pairs
OFFCh.1&2
