K-MIX EDITOR
98
INPUT TRIM
The input trim knob controls the input trim level of the currently selected
channel.
• Turn clockwise to increase the value; turn counterclockwise to
decrease the value.
• A specic value may be entered into the accompanying number
box as an alternative way of setting the trim level.
Channels 1–2 have a different range than channels 3–8:
• Range (Channels 1–2): 0dB – +60dB
• Range (Channels 3–8): -20dB – +40dB
RUMBLE FILTER
K-Mix’s rumble lter is an adjustable high-pass lter intended for ltering
out low frequency rumbles and handling noise that may occur when
using microphones as input.
BYPASS BUTTON
Toggles the input rumble lter for the currently selected channel on
or off.
• The button will light up white when enabled (rumble lter on).
• The button will go dark when disabled (rumble lter off).
• By default, the rumble lter will be off.
RUMBLE FILTER FREQUENCY
Controls the center frequency of the input rumble lter.
• Turn clockwise to increase the frequency; turn counterclockwise to decrease the frequency.
• A specic value may be entered into the accompanying number box as an alternative way
of setting the frequency.
• Range: 40Hz – 400Hz
Input Trim
1.50 dB
224 Hz
Rumble Filter
This is an editor-only parameter. It may not be adjusted from the mixer.
This is an editor-only parameter. It may not be adjusted from the mixer.
