K-MIX EDITOR
86
CONNECTION SYNC PRESET
CONNECTION SYNC is a preset that cannot be modied, reordered, or deleted, and is always at
the top of the preset list. It is used to store K-Mix’s current state when the mixer is initially connected
to the K-Mix Editor. It is also used when you change presets from the board while connected to the
editor.
This exists so you don’t lose any unsaved changes you may have made on the mixer before
connecting to the editor.
SYNC ON CONNECT BEHAVIOR
Upon opening the K-Mix Editor with a K-Mix connected to the computer, the editor syncs up with
the mixer’s current settings.
1. Connect K-Mix to computer via USB.
2. Open the K-Mix Editor.
3. The editor syncs up all global parameters with the mixer. The editor automatically updates
to whatever the mixer’s global parameters are currently set to.
4. The editor reads the mixer’s current per preset parameter states and stores them into the
CONNECTION SYNC preset.
5. To save this as a preset (in the editor), click the SAVE AS button while the CONNECTION
SYNC preset is selected.
6. Give the new preset a name and you’re done!
CHANGING PRESETS ON K-MIX WHILE CONNECTED TO EDITOR BEHAVIOR
If a preset change is initiated from the K-Mix hardware while connected to the K-Mix Editor, the
editor will sync those changes using the CONNECTION SYNC preset.
1. Connect K-Mix to computer via USB.
2. Open the K-Mix Editor.
3. The editor reads the mixer’s current parameter states and stores them into the
CONNECTION SYNC preset.
4. Press the [PRESET] button on the K-Mix hardware.
5. Select one of the 12 presets.
6. The mixer loads the selected preset’s settings.
7. The editor automatically switches over to the CONNECTION SYNC preset.
8. The CONNECTION SYNC preset is updated with the newly selected preset’s settings.
5.1.1.2 – SAVE BUTTON
The SAVE button is, oddly enough, used to save any changes made to the currently
selected preset.
When a change has been made to the preset, the SAVE button lights up magenta
