GETTING STARTED
17
STANDALONE POWER VIA USB POWER SUPPLY
It is also possible to power K-Mix from a standard AC power outlet using a 5V USB power supply
(included with K-Mix). The power supply must be capable of putting out a minimum of 500mA of power
to ensure K-Mix will work properly; the power supply that ships with K-Mix can output 1.5A.
1. Connect a mini-USB cable to K-Mix’s CONTROL port on the back panel.
2. Connect the other end of the mini-USB cable to a USB power supply.
3. Plug the USB power supply into a power outlet.
4. Turn on K-Mix by pressing the [ ] button.
+5V DC
1.5A
It is also possible to perform the above steps using a micro-USB cable and the
AUDIO port, instead of a mini-USB cable and the CONTROL port. Both methods are
perfectly capable of powering K-Mix from a USB power supply.
