GETTING STARTED
21
2.3.5 – TO PHONO LEVEL DEVICES
Phono level signals can be connected to inputs 3–8 on K-Mix. Phono level devices, like turntables, typically
have RCA connectors; it is likely you will need RCA to 1/4” TS adapters or and RCA to 1/4” TS cable in order
to connect to K-Mix. The following instructions are written as though this is the case.
1. Connect an RCA cable to your phono level device.
2. Connect the other end of the RCA cable to an RCA to 1/4” TS adapter.
3. Connect the 1/4” TS end to K-Mix input 3–8.
There are internal line/phono switches on K-Mix inputs 3–8 that must manually be set
to “Phono” using the K-Mix Editor. By default these switches are set to “Line”.
Outputs Inputs
1
4
3
6
5
8
7
2
3
6
5
8
7
4
2 1
