K-MIX HARDWARE
68
4.2.18.1 – WHAT DO THE CONTROLS DO?
FADER BEHAVIOR
The faders are not used when the [+48V] button is held down; they will not respond to touch and
their LEDs will be off.
ROTARY BEHAVIOR
The rotaries are not used when the [+48V] button is held down; they will not respond to touch and
their LEDs will be off.
CHANNEL SELECT BUTTON BEHAVIOR
While the [+48V] button is held down, channel select buttons 1 and 2 are used to toggle phantom
power on/off for their respective input channels. The channel select button’s LED is used to
represent the current phantom power state.
• Green = Phantom power on
• Red = Phantom power off
The master channel select button is used to toggle between +15V and +48V phantom power
voltage levels. The channel select button’s LED is used to represent the current voltage level being
provided by phantom power.
• Green = +48V
• Red = +15V
4.2.18.2 – TURNING PHANTOM POWER ON/OFF
To turn phantom power on/off, do the following:
1. Press and hold the [+48V] button.
2. Press channel select button 1 to toggle the phantom power state for channel 1. The LED will turn
green if phantom power is on, or red if phantom power is off.
3. Press channel select button 2 to toggle the phantom power state for channel 2.
4. Release the [+48V] button to return to the mode you were previously in.
VISUAL FEEDBACK
In addition to the channel select button LEDs, there are also two blue LEDs above the master
channel select button. These show the current on/off state of phantom power for input channels 1
and 2.
When phantom power is turned on it will take a few seconds to fully ramp up to the
proper voltage level. The +48V LEDs above the master fader will blink while this is
happening.
