K-MIX HARDWARE
70
• Press any channel select button, 1–8, to monitor that channel’s input signal, pre-fader and post-
DSP.
The master channel select button is used to make the headphone output act as its own discrete
output, effectively adding an extra two outputs to K-Mix.
[MAIN], [AUX1], [AUX2], [AUX3] BEHAVIOR
In Phones Mode, the [MAIN], [AUX1], [AUX2], and [AUX3] mode buttons are used to select one of
the four stereo output bus pairs as the monitor point for the headphone output.
• Press the [MAIN] button to monitor the main output bus, the [AUX1] button to monitor the Aux
1 output bus, etc.
4.2.19.2 – ADJUSTING THE HEADPHONE OUTPUT LEVEL
Adjusting the overall level of the headphone output is simple:
1. Enter Phones Mode by pressing the [ ] button.
2. Move the master fader up to increase the output level; move the fader down to decrease the
output level.
3. That’s it! Press the [ ] button again to exit Phones Mode and return to the mode you were
previously in.
4.2.19.3 – CHANGING THE HEADPHONE MONITORING POINT
You can set the headphone output to monitor any of the eight input channels or any of the four stereo
output bus pairs.
MONITORING AN INPUT CHANNEL
When monitoring an input channel, the signal will be tapped post-DSP (EQ, Comp, Gate) and pre-
fader.
To monitor one of the eight input channels via the headphone output, do the following:
1. Enter Phones Mode by pressing the [ ] button.
2. Press one of the channel select buttons 1–8 to monitor its respective input channel; its LED will
turn green. 1 will monitor input channel 1, 2 will monitor input channel 2, etc.
MONITORING AN OUTPUT BUS
When monitoring an output bus (Mains, Aux 1, Aux 2, Aux 3), the signal will be tapped toward the
very end of the signal chain, just before the output faders.
To monitor one of the four stereo output bus pairs via the headphone output, do the following:
1. Enter Phones Mode by pressing the [ ] button.
2. Press either the [MAIN], [AUX1], [AUX2], or [AUX3] mode buttons to monitor its respective
output bus; the selected mode button’s LED will light up blue. The headphone output is now
monitoring the selected output bus.
