9-12 Stepping and Scanning
SCPI programming - stepping and scanning
Commands to scan are listed in Table 9-1. Notice that many commands from the TRIGger
Subsystem are used for scanning. See Section 7 for details on triggering.
Notes:
1. The <list> parameter is formatted as follows:
<list> = (@X:Y)
Where: X is the Min channel
Y is the Max channel
2. The parameters are explained as follows:
NONE - Disables all operations associated with a scan.
INTernal - Enables an internal scan.
EXTernal - Enables an external scan.
3. Defaults for trigger count:
SYSTem:PRESet sets the count to INF (infinite).
*RST sets the count to 1.
Table 9-1
SCPI commands - stepping and scanning
Commands Description Default
For ROUTe Subsystem:
:ROUTe ROUTe Subsystem:
:SCAN Scanning:
:INTernal Internal Scan:
:CCOunt <n> Specify number of Channel 1 readings; 1 to
1023
1
[:EXTernal] <list> Specify external scan list: 2 to 800 (see note 1). 1-10
:LSELect <name> Select scan operation: NONE, INTernal or
EXTernal (see Note 2).
NONE
For TRIGger Subsystem:
:TRIGger Trigger commands:
:SOURce <name> Select control source: IMMediate, TIMer, MANual,
BUS, or EXTernal.
IMMediate
:TIMer <n> Set timer interval: 0 to 999999.999 (sec.). 0.1
:COUNt <n> Set trigger count: 1 to 9999 or INF. (see Note 3)
:DELay <n> Set delay: 0 to 999999.999 (sec.). 0
:AUTO <b> Enable or disable auto delay.
:SAMPle Sample Counter
:COUNt <n> Set sample count: 1 to 1024. 1
