Keithley 2182 User Manual

Additional SCPI Commands 15-13
Figure 15-9
Operation event enable register
:CONDition? command
:CONDition?
:STATus:MEASurement:CONDition? Read Measurement Condition Register
:STATus:QUEStionable:CONDition? Read Questionable Condition Register
:STATus:OPERation:CONDition? Read Operation Condition Register
Description
These query commands are used to read the contents of the condition registers. Each set of
event registers (except the Standard Event register set) has a condition register. A condition
register is similar to its corresponding event register, except that it is a real-time register that
constantly updates to reflect the present operating status of the instrument. See [:EVENt] for
register bit descriptions.
After sending one of these commands and addressing the Model 2182 to talk, a decimal value
is sent to the computer. The binary equivalent of this decimal value indicates which bits in the
register are set.
For example, if sending :stat:meas:cond? returns a decimal value of 512 (binary
0000001000000000), bit B9 of the Measurement Condition Register is set indicating that the
trace buffer is full.
Idle MeasTrig
B15 - B11 B10
B9 B8 B7, B6 B5
B4
B3-B1
B0
(2 )
10
1024
(2 )
4
(2 )
5
1632
0/1 0/10/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Enable Operation Event
0=Disable (Mask) Operation Event
Events : Idle = Idle state of the 2182
Filt = Filter Settled
Trig = Trigger Layer
Meas = Measuring
Cal = Calibrating
Filt
(2 )
8
256
Cal
(2 )
0
1
0/10/1
