D-2 Model 182 Emulation Commands
The Model 2182 can be configured to accept device-dependent commands of the Keithley
Model 182 Sensitive Digital Voltmeter. The commands for controlling the Model 2182 with the
182 language are provided in Table D-1. For details on Model 182 operation, refer to the
Model 182 Instruction Manual.
Since the architecture of the Model 2182 differs from that of the Model 182, some commands
are different and cannot be used. Be sure to refer to the notes at the end of the table for
information on command restrictions.
CAUTION The 182 language is intended to be used only over the IEEE-488 bus. Using
front panel controls in conjunction with this language may cause erratic
operation. In this case, results cannot be guaranteed.
Table D-1
Model 182 device-dependent command summary
Mode Command Description Note
Display ASCII String A0 Restore display to normal 1
A1,string Display string (up to 12 characters)
Display Resolution B0 5½-digit resolution
B1 6½-digit resolution
B2 3½-digit resolution
B3 4½-digit resolution
Calibration None C (Calibration) commands not supported 2
Filter Damping D0 Configure filter damping off (same as P2)
D1 Configure filter damping on (same as P3)
Reading Source F0 Latest reading from A/D converter
F1 One reading from buffer
F2 All readings in buffer
F3 Maximum value in buffer
F4 Minimum value in buffer
Reading Format G0 Reading only 3
G1 Reading with prefix
G2 Reading with buffer location
G3 Reading with buffer location and prefix
Immediate Trigger H0 Initiate manual trigger 4
Buffer Configuration I0 Disable buffer 5
I1,value Buffer on, value = buffer size
Analog Output J0 Disable analog output relative 6
Relative J1 Enable analog output relative using last reading as Rel
value
J2,value Enable analog output relative using value (±1e–9 to ±120)
J3 Enable analog output relative
EOI, Bus Hold-off K0 Enable EOI, enable bus hold-off on X
K1 Disable EOI, enable bus hold-off on X
