Keithley 2700 Service Manual

Replaceable Parts 6-3
Table 6-1
Model 2700 motherboard parts list
Circuit Designation Description Keithley Part No.
BT100 L1 BATTERY, 3.6V, 950MAH BA-51
C102 CAP, 0.01UF, 10%, 1000V, CERAMIC C-64-.01
C104 CAP, 100UF, 20%, 63V, ALUM ELEC C-403-100
C105 CAP, 0.22UF, 20%, 400V, FILM C-513-.22
C106,C291,C292 CAP, 15P, 1%, 100V, CERAMIC C-512-15P
C107,116,118,122,124,125,128,133,136 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C108 CAP, 0.1UF, 20%, 100V, CERAMIC C-436-.1
C109 CAP, 2.2UF, 20%, 63V, POLYCARB C-480-2.2
C110,C226,C254,C263 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C111,C103,C117,C147,C151 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C112,C248 CAP, 0.01, 5%, 50V, NPO C-514-.01
C113,C114,C119,C126,C247 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C115 CAP, 0.33UF, 20%, 63V, POLYCARBONATE C-482-.33
C120 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C121,C134,C140,C251,C287 CAP, 47PF, 10%, 100V, CERAMIC C-451-47P
C123,C245 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C131,C148 CAP, 1000U, 20%, 35V, ALUM ELEC C-595-1000
C132 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C137 CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
C138,139,142,127,149,152-155,
159-163,144
CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C141,143,150,158,176,219,220,222,224 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C145,C240 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C146 CAP, 1000UF, ±20%, 16V, ALUMINUM C-488-1000
C156,C281 CAP, 3300U, 20%, 16V, ALUM ELEC C-592-3300
C157 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C167-170,172-174,178,180,182,183,
185-187
CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C171,C177 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C175,C209 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C179,C266 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C190,193,194,197-199,201-208,210,
212-218
CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C221,223,225,227,230,232-234,237,250,
290
CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C241 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C242,C243,C283,C284,C246,C249 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C244,C267,C272,C278,C282 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C252,C253 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C255-262,C268,C129,C130 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C264,C265 CAP, 22P, 5%, 100V, CERAMIC C-465-22P
C269,C270,C271 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C285,C286,C288,C289 CAP, 47PF, 10%, 100V, CERAMIC C-451-47P
CR102,CR103 DIODE, BRIDGE, VM18 RF-52
CR104 DIODE, SILICON, W04M RF-46

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
