Keithley 2700 Service Manual

Replaceable Parts 6-13
Table 6-7
Model 7703 parts list
Circuit Designation Description Keithley Part No.
C1,C9,C20,C2,C23,C24,C25,C26,C27 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C22 CAP, 4.7U, 10%, 35V, TANTALUM C-476-4.7
C3,C4-C8, C10-C14,C19,C21 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
CR1,CR2 ULTRAFAST POWER RECTIFIER RF-107
J1015 CONN, RT ANGLE DUAL ROW RECEPT CS-1065-1
K1-K35 REED RELAY RL-237
P1016,P1017 CONN, RT ANGLE SEL CS-1061-1 CS-1062
Q1 P CHANNEL TMOSFET TG-392
R1,R7,R8,R4,R5,R6,R9,R10,R11 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R2 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R3 RES, 69.8K, 1%, 1W, THICK FILM R-418-69.8K
TP1,TP2 SURFACE MOUNT PCB TEST POINT CS-1026
U1 IC, TINYLOGIC CMOS INVERTER IC-1282
U2 IC, RETRIG., MULTIVIB, 74HC123AM IC-788
U3 IC, 2.5V, CASCADABLE SERIAL EEPROM LSI-212
U4 IC, 2 - INPUT AND GATE IC-1140
U6,U7,U8,U9,U10 IC, 8-BIT INPUT LATCH DRIVER IC-1342
BOTTOM CARD COVER 7703-301B
TOP CARD COVER 7703-302C
MASS TERM BRACKET 7703-303-1A
