Keithley 2700 Service Manual

6-12 Replaceable Parts
Table 6-6
Model 7702 parts list
Circuit Designation Description Keithley Part No.
C1,C3,C9,C10,C11,C12,C13,C14 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C16 CAP, 220U, 20%, 10V, TANTALUM C-558-220
C17,C18,C19,C20,C21,C22,C23,C24,C2,C6 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C25 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C4 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C5 CAP, 4.7U, 10%, 35V, TANTALUM C-476-4.7
CR1,CR22,CR45 DIODE, DUAL SWITCHING, BAV99L RF-82
CR2-CR21,CR23-CR42 DIODE, DUAL SWITCHING, BAV99L RF-82
CR43,CR44,CR46,CR47 DIODE, SWITCHING, MMBD914 RF-83
F1,F2 FUSE, 3A FU-107-1
J1 CONN, RT ANGLE DUAL ROW RECEPT CS-1065-1
K1-K41,K44-K47 SINGLE COIL LATCH RELAY RL-225
K42,K43 NON LATCHING RELAY RL-242
Q1 N-CHANNEL/P-CHANNEL POWER MOSFET TG-360
Q2,Q7 DUAL PNP DIGITAL TRANS TG-385
Q3,Q4,Q6 DUAL PNP DIGITAL TRANS TG-386
Q34,36,38,40,42,44,46,50,52,54,56,56,60 TRANS, PNP SILICON TG-388
Q35,37,39,41,43,45,47,51,53,55,57,59,65 TRANS, NPN SILICON TG-389
Q5 P CHANNEL TMOSFET TG-392
Q62,64,66,68,70,72,74,76,78,80,82,84,86 TRANS, PNP SILICON TG-388
Q63,65,67,69,71,73,75,77,79,81,83,85,87 TRANS, NPN SILICON TG-389
Q8,10,12,14,16,18,20,22,24,26,28,30,32 TRANS, PNP SILICON TG-388
Q88 TRANS, PNP SILICON TG-388
Q89 TRANS, NPN SILICON TG-389
Q9,11,13,15,17,19,21,23,25,27,29,31,33 TRANS, NPN SILICON TG-389
R1 RES, 69.8K, 1%, 1W, THICK FILM R-418-69.8K
R12,R55 RES, 137, 1%, 125MW, METAL FILM R-391-137
R13,R14 RES, 3.01K, 1%, 125MW, METAL FILM R-391-3.01K
R15-R54,R57-R96 RES, 4.22K, 1%, 125MW, METAL FILM R-391-4.22K
R3,108,109,110,111,112,113,2,5,6 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R4 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
TE101-TE122 CONN, 4 PIN, JOLO BB-125-04 TE-115-4
U1,U2,U3,U4,U5,U6 IC, 8 STAGE SHIFT/STORE, MC14094BD IC-772
U14 IC, RETRIG., MULTIVIB, 74HC123AM IC-788
U16 IC, 2.5V, CASCADABLE SERIAL EEPROM LSI-212
U25 IC, TINYLOGIC CMOS INVERTER IC-1282
U26,U27 IC, 2 - INPUT AND GATE IC-1140
BOTTOM CARD COVER 7702-301C
TOP CARD COVER 7702-302C
COMPRESSION SPRING SP-7-3
