Specifications A-7
GENERAL SPECIFICATIONS:
POWER SUPPLY: 100V / 120V / 220V / 240V ±10%.
LINE FREQUENCY: 45Hz to 66Hz and 360Hz to 440Hz, automatically sensed at power-up.
POWER CONSUMPTION: 28VA.
OPERATING ENVIRONMENT: Specified for 0°C to 50°C. Specified to 80% RH at 35°C.
STORAGE ENVIRONMENT: –40°C to 70°C.
BATTERY: Lithium battery-backed memory, 3 years @ 23°C.
WARRANTY: 3 years.
EMC: Conforms to European Union Directive 89/336/EEC EN61326-1.
SAFETY: Conforms to European Union Directive 73/23/EEC EN61010-1.
VIBRATION: MIL-PRF-28800F Class 3, Random.
WARM-UP: 2 hours to rated accuracy.
DIMENSIONS:
Rack Mounting
: 89mm high × 213mm wide × 370mm deep (3.5 in × 8.375 in × 14.563 in).
Bench Configuration (with handle and feet): 104mm high × 238mm wide × 370mm deep (4.125 in × 9.375 in × 14.563 in).
SHIPPING WEIGHT: 6.5kg (14 lbs.).
DIGITAL I/O: 2 inputs, 1 for triggering and 1 for hardware interlock. 5 outputs, 4 for Reading Limits and 1 for Master Limit. Outputs are TTL com-
patible or can sink 250mA, diode clamped to 33V.
TRIGGERING AND MEMORY:
Window Filter Sensitivity:
0.01%, 0.1 %, 1%, 10%, or Full-scale of range (none).
Reading Hold Sensitivity: 0.01%, 0.1 %, 1%, or 10% of reading.
Trigger Delay: 0 to 99 hrs (1ms step size).
External Trigger Delay: <2ms.
External Trigger Jitter: <1ms.
Memory Size: 55,000 readings.
MATH FUNCTIONS: Rel, Min/Max/Average/Std Dev/ Peak-to-Peak (of stored reading), Limit Test, %, and mX + b with user defined units dis-
played.
REMOTE INTERFACE:
Keithley XLinx Up & Running starter software
GPIB (IEEE-488.2) and RS-232C.
SCPI (Standard Commands for Programmable Instruments)
LabVIEW Drivers
TestPoint Drivers
ACCESSORIES SUPPLIED: Model 1751 Safety Test Leads, User Manual, Service Manual.
