Keithley 2700 Service Manual

A-6 Specifications
AC OPERATING CHARACTERISTICS
7
60Hz (50Hz) Operation
Function Digits Readings/s Rate Bandwidth
ACV, ACI 6.5
8
2s/Reading SLOW 3 Hz–300 kHz
6.5
8
1.4 (1.1) MED 30 Hz–300 kHz
6.5
9
4.8 (4) MED 30 Hz–300 kHz
6.5
9
35 (28) FAST 300 Hz–300 kHz
Frequency, 6.5 1 (1) SLOW 3 Hz–300 kHz
Period 5.5 9 (9) MED 30 Hz–300 kHz
4.5 35 (35) FAST 300 Hz–300 kHz
4.5
10
65 (65) FAST 300 Hz–300 kHz
AC System Speeds
7,11
RANGE CHANGES
12
: 4/s (3/s).
FUNCTION CHANGES
12
: 4/s (3/s).
AUTORANGE TIME: < 3s.
ASCII READINGS TO RS-232 (19.2k baud): 50/s.
MAX. INTERNAL TRIGGER RATE: 300/s.
MAX. EXTERNAL TRIGGER RATE: 250/s.
AC Notes
1.20 % overrange except on 750V and 3A.
2.Specification are for SLOW mode and sine wave inputs >5% of range. SLOW and MED are multi-sample A/D conversions. FAST is DETector:BANDwidth
300 with nPLC = 1.0.
3.Applies to 0°–18°C and 28°–50°C.
4.For square wave inputs >10% of ACV range, except 100mV range. 100mV range frequency must be >10Hz if input is <20mV.
5.Applies to non-sine waves >5Hz.
6.For 1kΩ unbalance in LO lead.
7.Speeds are for 60Hz (50Hz) operation using factory defaults operating conditions (*RST). Autorange off, Display off, Limits off, Trigger delay=0. Includes
measurement and binary data transfer out GPIB.
8.0.01% of step settling error. Trigger delay = 400ms.
9.Trigger delay = 0.
10.Sample count = 1024.
11.DETector:BANDwidth 300 with nPLC = 0.01.
12.Maximum useful limit with trigger delay = 175ms.
Internal Scanner Speeds:
Into and Out of Memory to GPIB
1
7703 Scanning DCV 185/s
7703 Scanning DCV with Limits or Time Stamp On 150/s
7703 Scanning ACV
2, 3
155/s
7703 Scanning DCV alternating 2W 60/s
7702 Scanning DCV 60/s
7700 Scanning Temperature (T/C) 55/s
Internal Scanner Speed Notes:
1. Speeds are 60Hz or 50Hz operation using factory default conditions (*RST). NPLC = 0.01. Auto Zero off, Auto Range off, and Display off. Sample count
=1024. Includes measurement and binary data transfer out GPIB.
2. Detector Bandwidth = 300.
3. For Auto Delay On = 1.8/s.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
