Keithley 2700 Service Manual

Replaceable Parts 6-9
Table 6-3
Model 2700 connector board parts list
Circuit Designation Description Keithley Part No.
J1009 CONN, MALE, 3-PIN CS-612-1
J1011 CONN, FEMALE, 8-PIN CS-612-8
J1013 CONN, RT ANGLE HEADER CS-1066-1
J1015,J1016 CONN 2 ROWS OF 16 PINS CS-736-4
L601,L602 FERRITE CHIP, 600 OHM, BLM32A07 CH-62
R600,R601 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R602,603,607,608,609,610,611,612 RES, 475, 1%, 125mW, METAL FILM R-391-475
R604,R604,R606 RES, 475, 1%, 125mW, METAL FILM R-391-475

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
