Keithley 2700 Service Manual

Calibration Reference B-3
Command Description
:CALibration
:PROTected
:DC
:STEP10 <NRf> 10mA DC step.
:STEP11 <NRf> 100mA DC step.
:STEP12 <NRf> 1A DC step.
:AC AC cal steps.
:STEP1 10mV AC at 1kHz step.
:STEP2 100mV AC at 1kHz step.
:STEP3 100mV AC at 50kHz step.
:STEP4 1V AC at 1kHz step.
:STEP5 1V AC at 50kHz step.
:STEP6 10V AC at 1kHz step.
:STEP7 10V AC at 50kHz step.
:STEP8 100V AC at 1kHz step.
:STEP9 100V AC at 50kHz step.
:STEP10 700V AC at 1kHz step.
:STEP11 100mA AC at 1kHz step.
:STEP12 1A AC at 1kHz step.
:STEP13 2A AC at 1kHz step.
:STEP14 1V AC at 3Hz step
1
.
:STEP15 1V AC at 1kHz step
1
.
NOTE: Upper-case letters indicated short form of each command. For example, instead of sending
“:CALibration:PROTected:INITiate,” you can send “:CAL:PROT:INIT.”
1
DC:STEP0, AC:STEP14, and AC:STEP15 are one-time factory calibration points and are valid only in manufacturing calibration
mode.
Table B-1 (Continued)
Remote calibration command summary

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
