6-6 Replaceable Parts Model 2701 Service Manual
R119,R384,R385 RES, 15K, 1%, 1/4W, METAL FILM R-391-15K
R123 RES, 73.2K, 1%, 100MW, THICK FILM R-418-73.2K
R126,R128,R185,R275 RES, 475, 1%, 1/4W, METAL FILM R-391-475
R129 RES, 215, 1%, 100MW, THICK FILM R-418-215
R132,R139,R148,R163 RES, 24K, 5%, 1W, 200V, THICK FILM R-437-24K
R135 RES, 33.2K, 1%, 100MW, THICK FILM R-418-33.2K
R137,R143,R152,R164 RES, 100K, 1%, 1/4W, METAL FILM R-391-100K
R138,R141,R414,R88 RES, 100, 1%, 1/4W, METAL FILM R-391-100
R140,R165,R184,R187,R190,R200,R204,R206 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R142 RES, 10, 5%, 125MW, METAL FILM R-375-10
R145,R156,R195,R199,R202,R208,R213,R257 RES, 100, 1%, 100MW, THICK FILM R-418-100
R146 RES, 1.1M, 5%, 125MW, METAL FILM R-375-1.1M
R147 RES, 732K, 1%, 100MW, THICK FILM R-418-732K
R149,R386,R387 RES, 1.5K, 1%, 100MW, THICK FILM R-418-1.5K
R150,R231,R325-R328,R346,R388 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R151,R166 RES, 1.5K, 1%, 100MW, THICK FILM R-418-1.5K
R153 RES NET, 3.6K, MICRO DIVIDER TF-246-1
R157 RES, 499, 1%, 100MW, THICK FILM R-418-499
R158 RES, .1, 1%, 3W R-475-.1
R159,R182,R272 RES, 1K, 1%, 1/4W, METAL FILM R-391-1K
R167,R173,R197,R256,R284,R288,R298,R340 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R169,R87 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R170 RES, 100K, .1%, .125W, THIN FILM R-456-100K
R171 RES, 1K, .1%, .125W, THIN FILM R-456-1K
R172,R339,R343,R62 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R174,R224,R389,R70 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R178,R179,R280 RES, 49.9, 1%, 100MW, THICK FILM R-418-49.9
R180,R181 RES, 301, 1%, 100MW, THICK FILM R-418-301
R188 RES, 49.9, 1%, 1/4W, METAL FILM R-391-49.9
R189,R400,R401 RES, 3.01K, 1%, 1/4W, METAL FILM R-391-3.01K
R191,R193,R391,R395,R56,R71,R76 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R192 RES, 6.98K, 1%, 1/4W, METAL FILM R-391-6.98K
R194 RES, 7.06K, 1%, .125W, METAL FILM R-443-7.06K
R196 RES, 2K, 1%, 1/4W, METAL FILM R-391-2K
R198 RES, 70K, 1%, .3W, 300V, METAL FOIL R-449-70K
R201,R238 RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R205,R338 RES, 10, .5%, 1/8W, METAL FILM R-246-10
R209-R211,R214,R218-R220,R244,R392,R396 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R212,R217,R39,R40 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
Table 6-1 (Continued)
Model 2701 motherboard parts list
Circuit designation Description Keithley part no.
