Model 2701 Service Manual Replaceable Parts 6-7
R215,R216 RES, 4.42K, 1%, 1/4W, METAL FILM R-391-4.42K
R221,R222 RES, 2.21K, 1%, 1/4W, METAL FILM R-391-2.21K
R223 RES, 2.21K, 1%, 1/4W, METAL FILM R-391-2.21K
R225 RES, 470, 5%, 125MW, METAL FILM R-375-470
R226 RES, 475, 1%, 100MW, THICK FILM R-418-475
R228,R237,R252 RES, 249, 1%, 100MW, THICK FILM R-418-249
R23 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R230 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R232,R233,R236 RES, 100, 1%, 1/4W, METAL FILM R-391-100
R234 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R235,R245,R250,R255 RES, 475, 1%, 100MW, THICK FILM R-418-475
R239,R242 RES, 2.2, 5%, 125MW, METAL FILM R-403-2.2
R24 RES, 200, 1%, 100MW, THICK FILM R-418-200
R240 RES, 2.2, 5%, 125MW, METAL FILM R-403-2.2
R241 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R243 RES, 22.1K, 1%, 100MW, THICK FILM R-418-22.1K
R246 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
R247 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R248,R251 RES, 267, 1%, 1/2W, METAL FILM R-94-267
R249 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R259,R320 RES, 10, 10%, 100MW, THICK FILM R-418-10
R273,R274,R307,R314 RES, 475, 1%, 1/4W, METAL FILM R-391-475
R277 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R278,R281 RES, 357, 1%, 100MW, THICK FILM R-418-357
R279,R289,296,R299,R305,R319,R342,R390 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R287,R316,R317,R349 RES, 1.28M, .1%, 1/8W, METAL FILM R-176-1.28M
R290 RES, 49.9K, 1%, 1/4W, METAL FILM R-391-49.9K
R302,R303,R383 RES, 499, 1%, 100MW, THICK FILM R-418-499
R304 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R308 RES, 100, 1%, 100MW, THICK FILM R-418-100
R309 RES, 1K, .1%, 1/10W, METAL FILM R-263-1K
R310 RES, 9.09K, .1%, 1/10W, METAL FILM R-263-9.09K
R311 RES, 392, 1%, 100MW, THICK FILM R-418-392
R312,R313 RES, 332K,1%, 100MW, THICK FILM R-418-332K
R315 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R318 RES, 73.2K, 1%, 100MW, THICK FILM R-418-73.2K
R323 RES, 150, 1%, 100MV, THIN FILM R-438-150
R341 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R350 RES, 6.04K, 1%, 125MW, THIN FILM R-423-6.04K
Table 6-1 (Continued)
Model 2701 motherboard parts list
Circuit designation Description Keithley part no.
