6-8 Replaceable Parts Model 2701 Service Manual
R352 RES NET 50K, 1%, .5W, THICK FILM TF-243-50K
R353 RESISTOR NETWORK, 10K-10K TF-236
R354 RES NET, 5K, .1%, 668A TF-243-5K
R38,R95,R97-R100,R111,R118,R122,R127 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R382,R419,R801,R168,R69,R73,R74,R77,R79 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R394,R22,R54,R89,R90 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R4,R6 RES, 75, 1%, 100MW, THICK FILM R-418-75
R46,R131,R227,R229,R276,R282,R344,R345 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R5 RES, 10, 10%, 100MW, THICK FILM R-418-10
R50 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R52,R58,R63,R65,R144,R84,R85 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R55 RES, 5.49K, 1%, 100MW, THICK FILM R-418-5.49K
R66,R67 RES, 12.4, 10%, 100MW, THICK FILM R-418-12.4
R7 RES CAP NET, 50 OHM, 10%, 100P-20%, 1W TF-286-50-100P
R72 RES, 3.01K, 1%, 100MW, THICK FILM R-418-3.01K
R75,R78,R80,R81,R130,R154,R177,R183,R186 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R8,R13-R21,R25-R33,R35,R41-R45,R47-R49 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R86,R82,R83,R92-R94,R155,R162,R203,R207 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R9,R10,R34 RES, 200, 1%, 100MW, THICK FILM R-418-200
R91 RES, 56.2 1% .1W, THICK FILM R-418-56.2
R96 RES, 56.2 1% .1W, THICK FILM R-418-56.2
RV1 TRANSIENT VOLTAGE SUPPRESSOR VR-25
RV101,RV102 VAR, 576V METAL OXIDE, 510L40 VR-5
RV104,RV105 BIDIRECTIONAL TRANSIENT VOLT
SUPPRESSOR
VR-8
S101 SWITCH, PUSHBUTTON, 8 POLE SW-468
SA101 SURGE ARRESTOR, CG3-1.5AL SA-4
SA102,SA103 SURGE ARRESTOR SA-8
TP102,TP105,TP107 CONN, TEST POINT CS-553
TP103,TP104,DGND SURFACE MOUNT PCB TEST POINT CS-1026
U1 IC, COLDFIRE MICROPROCESSOR LSI-286
U10 IC, 32 BIT RISC PROCESSOR LSI-285
U101 IC, VOLTAGE REG, LM317M IC-846
U102,U118 IC, J-FET, OP-AMP, TLE2081CD IC-967
U103,U105,U111,U129 IC, CMOS ANALOG SWITCH, DG211DY IC-768
U104 IC, IRED AND PHOTO DIODE ARRAY IC-1468
U106,U109,U121,U130,U134 IC, 8 STAGE SHIFT/STORE, MC14094BD IC-772
U107,U108 IC, PHOTO DARLINGTON TRANS, PS2706-1 IC-1467
U110 IC, TRMS TO DC CONVERTER, 637JR IC-796
Table 6-1 (Continued)
Model 2701 motherboard parts list
Circuit designation Description Keithley part no.
