Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual Section 7: Sweep Operation
Custom sweep commands
Table 7-4 summarizes remote commands used for custom sweep operation. See Section 16,
“Configure list,” for more details on these commands.
Custom sweep programming example
As an example of custom sweep operation, assume a five-point sweep with the following
parameters:
Source and measure channel: Channel 1
Voltage sweep mode: List (custom sweep)
Sweep voltage points: 7 V, 1 V, 3 V, 8 V, 2 V
Source delay: 100 ms
Table 7-5 summarizes the basic remote command sequence for performing the custom sweep
described above.
Table 7-4
Custom sweep commands
Command Description
:SOUR[1]:VOLT:MODE LIST
:SOUR[1]:LIST:VOLT < list>
:SOUR[1]:LIST:VOLT:APP <list>
:SOUR[1]:LIST:VOLT:POIN?
:SOUR[1]:SWE:RANG <name>
:SOUR2:VOLT:MODE LIST
:SOUR2:LIST:VOLT < list>
:SOUR2:LIST:VOLT:APPend <list>
:SOUR2:LIST:VOLT:POINts?
:SOUR2:SWE:RANG <name>
Select channel 1 voltage list (custom) sweep mode.
Define Channel 1 V-source list (list = V1, V2, … Vn).
Add Channel 1 V-source list values (list = V1, V2, …Vn).
Query length of Channel 1 V-source list.
Select Channel 1 source ranging (name = BEST, AUTO, or
FIXed).
Select channel 2 voltage list (custom) sweep mode.
Define Channel 2 V-source list (list = V1, V2, … Vn).
Add Channel 2 V-source list values (list =V1, V2, …Vn).
Query length of Channel 2 V-source list.
Select Channel 2 source ranging (name = BEST, AUTO, or
FIXed).
Table 7-5
Custom sweep programming example
Command Description
*RST
:FORM:ELEM CURR1
:SOUR1:VOLT:MODE LIST
:SOUR1:LIST:VOLT 7,1,3,8,2
:TRIG:COUN 5
:SOUR1:DEL 0.1
:OUTP1 ON
:READ?
:OUTP1 OFF
Restore GPIB default conditions.
Select channel 1 measurement data.
Channel 1 list volts sweep mode.
7 V, 1 V, 3 V, 8 V, and 2 V Channel 1 sweep points.
Trigger count = Number of sweep points.
100 ms Channel 1 source delay.
Turn on Channel 1 source output.
Trigger sweep, request data.
Output 1 off.
