14 PRINCIPLES OF OPERATION
SYSTEM INFORMATION - 4HR & 4HC
ELECTRICAL
REFRIGERATION -
Refrig. Charge: R-404A / 11.5 oz. / 326.02 grams / No. 4 Stat Position
Compressor Manufacturer: Americold
Model: HP-110-3083
V.: 115/100 R.L.A.: 2.0
L.R.A.: 10 Phase 1
Overload Protector Americold #1456-3453
Start Relay T.I.: Americold #1456-3372
Start Capacitor V.A.C.: 165 M.F.: 88-108
Run Capacitor V.A.C.: 180 M.F.: 15
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: 5KSM51GG-37845
Condenser Diameter: 8" # of Blades: 3
Fan Blade Width of Blades: 1 7/8"
Power Cord A.W.G.: 14
A.: 15 @ 125V
Light Ballast Manufacturer: G.E.
Model: 89G457
Fluorescent Manufacturer: G.E.
Lamp F20T12 CW
Evaporator Cold Wall
Capillary Tube 7' of .031
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/240 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Suction Pressure - C.O. PSIG/Kpa 13 / 13 / 14 /
Discharge Pressure - C.O. PSIG/Kpa 196 / 224 / 246 /
Compressor Amps 1.8 1.8 1.8
Total Cabinet Amps 2.3 2.0 2.0
Cavity Temperature C.L. 0°F / -17°C 2°F / -16°C 3°F / -16°C
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 16
