18 PRINCIPLES OF OPERATION
SYSTEM INFORMATION - E4HR & E4HC (220V / 50 Hz)
ELECTRICAL E4HR2 & E4HC2 (220V / 60 Hz)
REFRIGERATION -
Refrig. Charge: R-404A / 11.5 oz. / 326.02 grams / No. 4 Stat Position
Compressor Manufacturer: Americold
Model: HP-110-12-3084
V.: 220 R.L.A.: 2.0
L.R.A.: 12.6 Phase: 1/50Hz.
Overload Protector T.I.: Americold #1456-3444
Start Relay T.I.: Americold #1456-3374
Start Capacitor V.A.C.: 250 M.F.: 108-130
Run Capacitor V.A.C.: 370 M.F.: 7.5
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: 5KSM51ECG3905
Condenser Diameter: 8" # of Blades: 3
Fan Blade Width of Blades: 1 7/8"
Power Cord A.W.G.: 14
A.: 15 @ 125V
Light Ballast Robertson #02025 (50Hz)
Robertson #02026 (60Hz)
Fluorescent Manufacturer: G.E.
Lamp F20T12/CW
Evaporator Cold Wall
Capillary Tube 7' of .031
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/240 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Cavity Temperature C.L. 0°F / -17°C 2°F / -16°C 3°F / -16°C
Suction Pressure - C.O. PSIG/Kpa 12 / 82 13 / 89 14 / 96
Discharge Pressure - C.O. PSIG/Kpa 206 / 1420 214 / 1475 239 / 1647
Compressor Amps 2.0 2.0 2.0
Total Cabinet Amps 2.3 2.3 2.3
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 20
