CABINET SPECIFICATIONS
4HC & 4HR/4HJ E4HC & E4HR E4HC2 & E4HR2
Temp. Range +10°F to -8°F
Capacity 4.6 Cu. Ft.
Capacity (3 Gal. Tubs) 4
Facings (3 Gal. Tubs) 4
Storage (3 Gal. Tubs) 0
Compressor Size 1/4 Hp.
Shipping Weight (App.) 235 lbs.
Condenser Type Bare Tube
Evaporator Type Cold Wall
Refrigerant R-404A
Refrigerant Control Capillary Tube
Defrost System Manual
Rated Amps 3.0 1.7 1.7
Electrical Specs. 115V, 60 Hz., 1 Ph. 220V, 50 Hz., 1Ph 220V, 60 Hz., 1 Ph.
Power Cord No. 16AWG
NSF Listing NSF7
Canopy Construction S.S. Top with Glass ends Straight or Curved Front Glass
Lids (Plexiglass) 1 Lid
Interior Finish White Baked Enamel on Galvanized Steel
Exterior Finish White Baked Enamel
Lighting One 20 Watt Bulb
Accessories Can Skirt Kit, Lid Locks, Dipperwell, Night Covers, Casters, Legs
DIMENSIONAL DATA
4 INTRODUCTION
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 6
