CANOPY PARTS LIST
CANOPY PARTS 57
CANOPY PARTS
Dipping Cabinets
Curved & Flat & Export
DESCRIPTION U/M QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.# QTY GR.#
01-0902-01 Glass Bracket, Top EA 2 - 2 - 2 - 3 - 3 - 3 - 3 -
02-0942-00 Glass Bracket, Top EA 2-2-3-3-
51-1502-* Lamp Channel Assembly EA 1 -01 1 -02 1 -03 1 -04 1 -05 1 -06 1 -07 1 -08
51-1503-* Lamp Channel Assembly EA 1 -01 1 -03 1 .02
01-1129-* Lamp Channel EA 1 -01 1 -02 1 -02 1 -03 1 -03 1 -04 1 -04
01-1128-* Lamp Channel EA 1 -01 1 -02 1 -03 1 -04
3 02-0936-00 Clamp Top End EA 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 -
05-1034-02 Corner Trim, RH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 -
05-1035-02 Corner Trim, RH EA 1-1-1-1-
05-1034-01 Corner Trim, LH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 -
05-1035-01 Corner Trim, LH EA 1-1-1-1-
626-6504-00 Tape, Double Sided FT 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 - 1.8 -
7 10-1061-02 Glass Channel, Vert. EA 2-2-2-2-
10-1042-00 Gasket, Glass (Curved) EA 3 - 3 - 3 - 3 - 3 - 3 - 3 -
19-1975-00 Lampholder EA 1 - 2 - 4 - 2 - 4 - 2 - 4 - 1 - 2 - 2 - 2 -
19-0088-00 Lampholder, W/Starter Soc. EA 1 - 2 - 2 - 2 - 1 - 2 - 2 - 2 -
10-0445-00 Lamp Shield &Cap, 40 Watt EA 2 - 2 - 2 - 2 - 2 - 2 -
10-0551-00 Lamp Shield &Cap, 20 Watt EA 1 - 2 - 2 - 1 - 2 -
19-0151-00 Lamp, 40 Watt EA 2 - 2 - 2 - 2 -
19-0149-00 Lamp, 20 Watt EA 1 - 2 - 1 - 2 -
19-1277-00 Lamp, 34 Watt (3500K) EA 2 - 2 -
19-1312-00 Lamp, 17 Watt (3500K) EA 2 -
11 26-1006-00 Tape, Cush. FT 2.25 - 4 - 4 - 5.5 - 5.5 - 7.25 - 7.25 - 2.25 - 4 - 5.5 - 7.25 -
19-0145-00 Starter, FS4 EA 2 - 2 - 2 - 2 -
19-0144-00 Starter, FS2 EA 1 - 2 - 1 - 2 -
05-1036-* Light Shield EA 1 -01 1 -02 1 -03 1 -04
05-0935-* Light Shield EA 1 -01 1 -02 1 -02 1 -03 1 -03 1 -04 1 -04
14 05-1197-02 Inside Post RH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 -
15 05-1197-01 Inside Post LH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 -
16 05-1192-01 Inside Post, Center EA 1 - 1 - 1 - 1 - 1 - 1 -
17 05-1031-* Frame, Lower Front EA 1 -01 1 -02 1 -02 1 -03 1 -03 1 -04 1 -04 1 -01 1 -02 1 -03 1 -04
20-0073-00 Glass, End EA 2 - 2 - 2 - 2 - 2 - 2 - 2 -
20-0076-00 Glass, End EA 2-2-2-2-
19 10-1061-01 Glass Channel, Horz. EA 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 -
20 02-0937-00 Clamp Bottom End EA 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 - 2 -
21 05-1015-02 Frame, Canopy End RH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 -
22 05-1015-01 Frame, Canopy End LH EA 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 - 1 -
23 05-1030-* Glass Retainer, Lower Front EA 1 -01 1 -02 1 -02 1 -03 1 -03 1 -04 1 -04 1 -01 1 -02 1 -03 1 -04
20-0072-* Glass, Front EA 1 -02 1 -02 1 -03 1 -03 1 -04 1 -04
20-0075-* Glass, Front EA 1 -01 1 -02 1 -03 1 -04
25 05-1193-01 Outside Post, Center EA 1 - 1 - 1 - 1 - 1 - 1 -
