PRINCIPLES OF OPERATION 15
SYSTEM INFORMATION - 8HR & 8 HC
ELECTRICAL
REFRIGERATION -
Refrig. Charge: R-404A / 17 oz. / 481.95 grams / No. 4 Stat Position
Compressor Manufacturer: Americold
Model: HP-117-1
V.: 115/100 R.L.A.: 3.0
L.R.A.: 21.4 Ph.: 1 HP:
1
⁄3
Overload Protector Americold #1456-3454
Start Relay T.I.: 8EA1206K1A
Start Capacitor V.A.C.: 165 M.F.: 88-108
Run Capacitor V.A.C.: 200 M.F.: 15
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: Morrill
Fan Motor Model: SPB9S1
Condenser Diameter: 8" # of Blades: 3
Fan Blade Width of Blades: 2 3/4"
Power Cord A.W.G.: 14
A.: 15 V.: 125
Light Ballast Manufacturer: G.E.
Model: 89G457(STD)
B232I120RH (3500K)
Fluorescent Manufacturer: G.E.
Lamp F20T12 CW (STD)
F17T8 / SP35 (3500K)
Evaporator Cold Wall
Capillary Tube 8' of .036
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/240 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Suction Pressure - C.O. PSIG/Kpa 9 / 12 / 13 /
Discharge Pressure - C.O. PSIG/Kpa 187 / 228 / 251 /
Compressor Amps 2.9 2.9 2.9
Total Cabinet Amps 3.5 3.5 3.5
Cavity Temperature C.L. 5°F / -15°C 7°F / -13°C 8°F / -13°C
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 17
