36 MAINTENANCE & REPAIR
LID SEAL REPLACEMENT
1. Remove lids from the cabinet.
2. Remove screws on the underside of the stainless
top on the server side of the cabinet.
3. Remove the stainless top from the cabinet.
4. Slide the lid seal off of the top channel.
5. Replace the lid seal with new correct art number.
Seal needs to be cut to fit the cabinet width.
6. Replace the stainless steel top with the lid seal
attached.
7. Replace screws along the stainless steel top server
side.
8. Replace lids on the cabinet.
The lid seal is located on the server side of the cabinet,
attached to the underside of the stainless steel top.
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 38
