CABINET SPECIFICATIONS
8HC & 8HR/8HJ & 8HF E8HC & E8HR E8HC2 & E8HR2
Temp. Range +10°F to -8°F
Capacity 12.0 Cu. Ft.
Capacity (3 Gal. Tubs) 12
Facings (3 Gal. Tubs) 8
Storage (3 Gal. Tubs) 4
Compressor Size 1/3 Hp.
Shipping Weight (App.) 365 lbs.
Condenser Type Bare Tube
Evaporator Type Cold Wall
Refrigerant R-404A
Refrigerant Control Capillary Tube
Defrost System Manual
Rated Amps 4.0 2.1 2.1
Electrical Specs. 115V, 60 Hz., 1 Ph. 220V, 50 Hz., 1 Ph. 220V, 60 Hz., 1Ph.
Power Cord No. 16AWG
NSF Listing NSF7
Canopy Construction S.S. Top with Glass ends Straight or Curved Front Glass
Lids (Plexiglass) 1 Lid
Interior Finish White Baked Enamel on Galvanized Steel
Exterior Finish White Baked Enamel
Lighting Two 20 Watt Bulbs Standard (17 Watt Bulbs on Special Cabinets with 3500 K Lighting)
Accessories Can Skirt Kit, Lid Locks, Dipperwell, Night Covers, Casters, Legs
DIMENSIONAL DATA
INTRODUCTION 5
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 7
