Kelvinator R-404A User Manual

SYSTEM INFORMATION - EKDC-87 & ECKDC-87 (220V / 50 Hz)
ELECTRICAL E16HR2 & E16HC2 (220V / 60 Hz)
REFRIGERATION -
Refrig. Charge: R-404A / 27 oz. / 765.45 grams / No. 4 Stat Position
Power Cord A.W.G.: 16
Amp: 15
Light Ballast VOSSLOH SCHWABE
Model: L36.291 (50Hz)
Robertson: 1-4025 (60 Hz)
Fluorescent Manufacturer: G.E.
Lamp F40T12CW
PRINCIPLES OF OPERATION 21
Compressor Mft: Copeland (3/4 HP)
Model: KAMB-007E-CAV
R.L.A.: 5.6 L.R.A.: 36.0
Phase: 208/230V 60 Hz.
200/220V 50 Hz.
Overload Protector Model No.: 071-0092-29
Start Relay G.E. 3ARR3CT3E5
Start Capacitor V: 220 M.F.: 145-174
Run Capacitor V.: 370 M.F.:10
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: KSM51GG3705
Condenser Diameter: 9-
1
⁄2"# Blades: 3
Fan Blade Width of Blades: 1-
29
⁄32"
Evaporator Cold Wall
Capillary Tube 9' of .049
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 125/250 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CAVITY TEMPERATURE 2°F / -17°C 4°F / -16°C 6°F / -14°C
Suction Pressure - C.O. PSIG/Kpa 8 / 55 10 / 69 12 / 82
Discharge Pressure - C.O. PSIG/Kpa 228 / 1572 257 / 1772 284 / 1958
Compressor Amps 7.4 7.5 8
Total Cabinet Amps 9.5 9.3 10
