BALLAST REPLACEMENT
BALLAST REPLACEMENT 45
The ballast is located in the machinery
compartment inside the electrical box.
1. Disconnect the power to the cabinet.
2. Remove the front grill.
3. Remove the electrical wiring box.
4. Disconnect the leads to the ballast.
5. Replace the ballast with correct part.
6. Reconnect the leads to the ballast.
7. Replace the electrical box assembly.
8. Replace the front grill.
9. Reconnect the power to the cabinet.
Dipping Cabinet 1298.02 2/3/03 1:15 PM Page 47
