PRINCIPLES OF OPERATION 17
SYSTEM INFORMATION - 16HR & 16HC
ELECTRICAL
Compressor Manufacturer: Americold
Model: HP-127-1
Volts: 115 R.L.A.: 4.2
L.R.A.: — Ph.: 1 Hz.: 60
Overload Protector Americold #1456-3321
Start Relay Americold #1456-3374
Start Capacitor V.: 125 M.F.: 189-227
Run Capacitor V.: 370 M.F.: 20
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: 5KSM51GG3784
V.: 115 Hz.: 60 Ph.: 1
Condenser Diameter: 9.5" # Blades: 3
Fan Blade Width of Blades: 1 29/32"
Power Cord A.W.G.: 16
A.: 15 V.: 125
Light Ballast Manufacturer: G.E.
Model: 8G3706 (STD)
B232I120RH (3500K)
Fluorescent Manufacturer: G.E.
Lamp F40T12CW (STD)
F32T8/SP35 (3500K)
Evaporator Cold Wall
Capillary Tube 7' of .042
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/240 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Suction Pressure - C.O. PSIG/Kpa 9 / 10 / 12 /
Discharge Pressure - C.O. PSIG/Kpa 207 / 234 / 262 /
Compressor Amps 3.8 3.8 3.9
Total Cabinet Amps 6.3 6.3 6.3
Cavity Temperature C.L. -.5°F / -18°C -.3°F / -17.9°C -1.2°F / -18.4°C
REFRIGERATION - Refrig. Charge: R-404A / 27 oz. / 765.45 grams / No. 4 Stat Position
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 19
