PRINCIPLES OF OPERATION 19
SYSTEM INFORMATION - E8HR & E8HC (220V / 50 Hz)
ELECTRICAL E8HR2 & E8HC2 (220V / 60 Hz)
REFRIGERATION -
Refrig. Charge: R-404A / 17 oz. / 481.95 grams / No. 4 Stat Position
Compressor Manufacturer: Americold
Model: HP-118-12
V.: 220 R.L.A.: 3.0
L.R.A.: 12.6 Phase: 1/50Hz.
Overload Protector Americold #1456-3321
Start Relay T.I.: 8EA14
Start Capacitor V.A.C.: 250 M.F.: 108-130
Run Capacitor V.A.C.: 370 M.F.: 7.5
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: 5KSM51ECG3905
Condenser Diameter: 8" # of Blades: 3
Fan Blade Width of Blades: 1 7/8"
Power Cord A.W.G.: 14
A.: 15 @ 125V
Light Ballast Robertson #02026
Fluorescent Manufacturer: G.E.
Lamp F20T12/CW
Evaporator Cold Wall
Capillary Tube 8' of .036
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/240 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Cavity Temperature Range 5°F / -15°C 7°F / -13°C 8°F / -13°C
Suction Pressure - C.O. PSIG/Kpa 13 / 89 15 / 103 16 / 110
Discharge Pressure - C.O. PSIG/Kpa 213 / 1468 250 / 1723 292 / 2013
Compressor Amps 2.9 3.0 3.1
Total Cabinet Amps 3.5 3.7 3.7
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 21
