CABINET SPECIFICATIONS
12HC & 12HR ECKDC-67 & EKDC-67 E12HC2 & E12HR2
Temp. Range +10°F to -8°F
Capacity 19.1 Cu. Ft.
Capacity (3 Gal. Tubs) 20
Facings (3 Gal. Tubs) 12
Storage (3 Gal. Tubs) 8
Compressor Size 1/3 Hp. 3/4 Hp. 3/4 Hp.
Shipping Weight (App.) 525 lbs.
Condenser Type Bare Tube
Evaporator Type Cold Wall
Refrigerant R-404A
Refrigerant Control Capillary Tube
Defrost System Manual
Rated Amps 8.0 4.1 4.1
Electrical Specs. 115V., 60 Hz, 1 Ph. 220V, 50 Hz, 1 Ph. 220V, 60 Hz, 1 Ph.
Power Cord Yes
NSF Listing NSF7
Canopy Construction S.S. Top with Glass ends Straight or Curved Front Glass
Lids (Plexiglass) 2 Lid
Interior Finish White Baked Enamel on Galvanized Steel
Exterior Finish White Baked Enamel
Lighting Two 30 Watt Bulbs Standard (32 Watt Bulbs on Special Cabinets with 3500 K Lighting)
Accessories Can Skirt Kit, Lid Locks, Dipperwell, Night Covers, Casters, Legs
DIMENSIONAL DATA
6 INTRODUCTION
Dipping Cabinet 1298.02 2/3/03 1:14 PM Page 8
