16 PRINCIPLES OF OPERATION
SYSTEM INFORMATION - 12HR & 12HC
ELECTRICAL
REFRIGERATION -
Refrig. Charge: R-404A / 25 oz. / 708.75 grams / No. 4 Stat Position
Compressor Manufacturer: Americold
Model: HP-127-1
Ph.: 1 Hz.: 60
Volts: 115 Amps: 4.2
Overload Protector Manufacturer: Americold
Start Relay Manufacturer: Americold
Start Capacitor V.: 125 M.F.: 189-227
Run Capacitor VAC: 370 M.F.: 20
Condenser Manufacturer: Heatcraft
Condenser Manufacturer: G.E.
Fan Motor Model: 5KSM51GG3784
Condenser Diameter: 9.5" # Blades: 3
Fan Blade Width of Blades: 1 29/32"
Power Cord A.W.G.: 16
A.: 15 V.: 125
Light Ballast Manufacturer: G.E.
Model: 89G457(STD)
B232I120RH(3500K)
Fluorescent Manufacturer: G.E.
Lamp F40T12CW (STD)
F32T8/SP35 (3500K)
Evaporator Cold Wall
Capillary Tube 7' of .042
Thermostat Manufacturer: Ranco
F. L .A .: 25
V.: 120/250 L.R.A.: 100
Warm Cut-in 11° Warm Cut-out —
Mid Cut-in -12° Mid Cut-out -24°
Cold Cut-in — Cold Cut-out -34°
AMBIENT TEMPERATURE 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
CONTROL SETTINGS #4 C.S. #4 C.S. #4 C.S.
Suction Pressure - C.O. PSIG/Kpa 9 / 10 / 11 /
Discharge Pressure - C.O. PSIG/Kpa 198 / 230 / 268 /
Compressor Amps 4.2 4.2 4.3
Total Cabinet Amps 6.1 6.1 6.2
Cavity Temperature 0°F / -17°C 1°F / -17°C 2°F / -16°C
